PRODUCT FEATURES AT GLANCE

• Two types of feeder for various package stocks.
• Standard friction feeder-for a regular paper surface, and high speed inspection this feeder is a standard option.
• Suction feeder-To avoid scratch marks on the sensitive cartons you can use suction feeder.

Inspection Unit

• Assembled the line scan colour camera from Chromasens Germany. The highest line rate in the world.
• Cameras in multi-station with specific lighting source with own patent.
• Vacuum under belt to flatten the cartons.
• Assembled with Industrial air condition to guarantee the suitable temperature for cameras.

Converyor Unit

• Two belts to clamp the cartons to make it stable and high-speed.
• Twin Rejection (Air & Plate) – The twin rejection means the machine have two (Air and Plate) type of rejections. We can choose the rejection depending upon the carton thickness. Air rejecter can be used for 90gsm to 400gsm and Plate Rejecter is for 100gsm to 700gsm & irregular shapes cartons.
• Rejection Unit – Machine have separate platform for rejected cartons and have mechanism to count the delivered cartons.
• Collection Unit / Delivery Unit-The platform for good one and it is easy to collect with auto counting of quantity collected. Also, have batch collection for good cartons.
• Automatic – Stacking system-For automatically collection of cartons at the end of the machine which is suitable for regular shape cartons.
